P-SFULVT Long Flute Square End Mill - 8 Fultes
Product Number：P-SFULVT
200 PLUS Nano End Mills，Diameter：6mm~25mm，Coating：TiSiN+/ P-nACo
-
Spec. Download
Cutting Condition Download
200 PLUS Nano End Mills Series General Application
Application: ~HRC65/ Iron, Carbon steel, Cast Iron, Alloy Steel, Tool Steel, Heat treatment Steel,Welding Steel
Main Character: Super Ultra Fine Micro Grain Carbide that has high toughness, coating TiSiN and wear-resisting, non-general titanium, aluminium is specialized in milling on M/C high hardness at a high speed and can carry on rough machining get to detailed process directly for heat treatment mould to reduce change times, improve machine flexible rate and shorten producing time.Features
• Unequal flute spacing and unequal lead design have excellent and long effect of anti-vibration during milling.
Characteristic：
Excellent anti-vibration effect
• Super Ultra Fine Micro Grain Carbide raw material with the most suitable flute geometry ensure to improve chip disposal and rigidity.
Long tool life
• With Super Ultra Fine Micro Grain Carbide raw material which has high temperature resistance and with P-nACo coating that can extend tool life.
• It's much easier to have finishing procedure on Hardened steel compare to general endmills.
200PLUS Ball nose & Corner radius type - surface and angle
• R angle:0~90˚ Negative angle design
• Specular surface
200PLUS square type - surface
• OD specular surface
• Cutting edge specular surface
Comparison
Series Grain Size Hardness (HRC) Coating Application 200 Nano 0.2μm ~65 TiSiN Super Hard Hardness 400 Nano 0.4μm ~60 nBS High Hardness 600 Nano 0.6μm ~50 AlTiN General
-
-
-
